RR01 Hardware Hex Adressen
00:ZGM_65
01:SI_SIM
02:SI_SZL
03:SI_SASL
04:SI_SASR
05:SI_STVL
06:SI_STVR
07:SI_SSFA
08:SI_SSBF
09:SI_SBSL
0A:SI_SBSR_N7
0D:SI_SSH
0E:SI_SFZ
12:DME
13:DME
18:GKE
1B:VVT_1
1E:VVT_2
20:RDC60
23:SVTRR01
24:CVM64
26:MMB2
29:DSC
2A:EMF
31:MMC
32:MMIC_Fond
34:RMMIF1
35:SVS
36:TEL
37:TH_AMP
38:REHCR1
39:EDCK
3A:KHI
3B:RNAV1
3C:CDC
3E:RADP1
3F:ASK
40:RCAS1
41:DWA65
42:CIM65
43:PM_POW
44:SHD_2_MDSE60_ab_03_03
45:RLS_1
46:WIM
47:AT
49:SEC_1
4A:SEM267
4B:VID65
4C:TM_FA
4D:TM_BF
4E:RTFHH1
4F:RTBHH1
50:SINE
53:IBOC
54:SDARS
58:ADPF
5B:DAB
5F:FLA65
60:RKOMB1
61:FBIE
62:MCGW
63:RMMI1
64:PDC
65:RBZM1
66:BZMF65
67:ZBE_ECO_Fr
68:ZBE_ECO_Fo
69:SMFH
6A:SMBFH
6B:HKL65
6C:RKFS
6D:SMF
6E:SMBF
70:LME65
73:RCID1
74:RCCHL
75:RCCHR
78:RIHKA1
7D:FDM1
9E:UEB2
DETAILANSICHT
| HEX | SGBD | Gruppe | Flashbar | F-Limit | F-Zugang | Cod.-Name |
|---|---|---|---|---|---|---|
| 00 | zgm_e65 | d_zgm | 1 | 16 | KLINE | |
| 01 | sim | d_sim | 1 | 0 | KLINE | SIM |
| 01 | sgm_60_2 | d_sim | 1 | 0 | KLINE | SGM |
| 02 | szl | d_szl | 1 | 0 | KLINE | SZL |
| 03 | sasl | d_sasl | 1 | 0 | KLINE | SASL |
| 04 | sasr | d_sasr | 1 | 0 | KLINE | SASR |
| 05 | stvl | d_stvl | 1 | 0 | KLINE | STVL |
| 06 | stvr | d_stvr | 1 | 0 | KLINE | STVR |
| 07 | ssfa | d_ssfa | 1 | 0 | KLINE | SSFA |
| 08 | ssbf | d_ssbf | 1 | 0 | KLINE | SSBF |
| 09 | sbsl | d_sbsl | 1 | 0 | KLINE | SBSL |
| 0A | sbsr | d_sbsr | 1 | 0 | KLINE | SBSR |
| 0D | ssh | d_ssh | 1 | 0 | KLINE | SSH |
| 0E | sfz | d_sfz | 1 | 0 | KLINE | SFZ |
| 12 | n73_r0 | d_motor | 1 | 20 | KLINE | RMOT |
| 13 | n73_l0 | d_motor2 | 1 | 20 | KLINE | LMOT |
| 18 | gs19 | d_egs | 1 | 20 | KLINE | |
| 18 | gs19b | d_egs | 1 | 14 | KLINE | |
| 18 | gsb233 | d_egs | 1 | 14 | KLINE | |
| 1B | vvt_b1_0 | d_vvt | 1 | 0 | KLINE | |
| 1E | vvt_b2_0 | d_vvt2 | 1 | 0 | KLINE | |
| 20 | rdc_60 | d_rdc | 1 | 0 | KLINE | RDC |
| 23 | svt_rrs2 | d_ars | 1 | 0 | KLINE | SVT |
| 24 | cvm_64 | d_cvm | 1 | 0 | KLINE | CVM |
| 26 | mmb2rr | d_rse | 1 | 0 | KLINE | MMB |
| 29 | dsc_e65 | d_dsc | 0 | 0 | ||
| 2A | emf_e65 | d_emf | 1 | 0 | KLINE | EMF |
| 31 | mmc_e65 | d_mmc | 1 | 0 | KLINE | MMC |
| 31 | mmc_65_2 | d_mmc | 1 | 0 | KLINE | MMC |
| 32 | mmifc | d_mmifc | 1 | 0 | KLINE | |
| 34 | mmi_gtf | d_mmif | 1 | 0 | KLINE, MOST_ASYNC | MMIF |
| 35 | svs_e65 | d_svs | 0 | 0 | ||
| 36 | tel_ece | d_tel | 1 | 0 | KLINE, MOST_ASYNC | TE65 |
| 36 | tel_usa | d_tel | 1 | 0 | KLINE, MOST_ASYNC | TUS |
| 36 | tele60_2 | d_tel | 1 | 0 | KLINE, MOST_ASYNC | TCUM |
| 36 | tele60_3 | d_tel | 1 | 0 | KLINE, MOST_CONTROL | TCUM |
| 37 | amp_e65 | d_amp | 1 | 0 | KLINE, MOST_ASYNC | |
| 38 | ehc2rr | d_ehc | 1 | 0 | KLINE | EHC |
| 39 | edc_k | d_edc | 1 | 0 | KLINE | EDC |
| 39 | edck65 | d_edc | 1 | 0 | KLINE | EDC |
| 3A | khi_e65 | d_khi | 1 | 0 | KLINE | |
| 3B | nav_e65 | d_nav | 0 | 0 | NAV | |
| 3B | cnav60 | d_nav | 1 | 0 | KLINE | |
| 3B | knav60 | d_nav | 1 | 0 | KLINE | |
| 3B | jnav60_3 | d_nav | 1 | 0 | CD, KLINE | |
| 3C | cdc_e65 | d_cdc | 1 | 0 | KLINE | |
| 3C | m_ipod | d_cdc | 0 | 0 | ||
| 3E | adp_rr | d_adp | 1 | 0 | KLINE | HKL |
| 3F | ask_e65 | d_ask | 1 | 0 | KLINE, MOST_ASYNC | ASK |
| 40 | cas | d_cas | 1 | 0 | KLINE | CAS |
| 41 | dwa_e65 | d_dwa | 1 | 0 | KLINE | DWAI |
| 41 | dwa_63 | d_dwa | 1 | 0 | KLINE | DWAI |
| 42 | cim | d_cim | 1 | 0 | KLINE | CIM |
| 43 | pow_e65 | d_pow | 1 | 0 | KLINE | PMA |
| 43 | pow_65_2 | d_pow | 1 | 0 | KLINE | PMA |
| 43 | pow_65_3 | d_pow | 1 | 0 | KLINE | PMA |
| 44 | sd_kwp | d_shd | 1 | 0 | KLINE | SHD |
| 45 | rls_e65 | d_rls | 1 | 0 | KLINE | RLS |
| 46 | wim_e65 | d_wim | 1 | 0 | KLINE | WIM |
| 47 | ant_e65 | d_anttu | 1 | 0 | KLINE, MOST_ASYNC | TUNER |
| 49 | secur1 | d_secur1 | 0 | 0 | KLINE | SEC1 |
| 4A | secur2 | d_secur2 | 1 | 0 | KLINE | SEC2 |
| 4B | vid_e65 | d_video | 1 | 100 | KLINE, MOST_ASYNC | |
| 4B | vid_65_2 | d_video | 1 | 100 | KLINE, MOST_ASYNC | |
| 4C | tmf_e65 | d_tmft | 1 | 0 | KLINE | TMFT |
| 4D | tmb_e65 | d_tmbt | 1 | 0 | KLINE | TMBT |
| 4E | tmfhe65 | d_tmfth | 1 | 0 | KLINE | TMFH |
| 4F | tmbhe65 | d_tmbth | 1 | 0 | KLINE | TMBH |
| 50 | sine_65 | d_sine | 0 | 0 | DWAS | |
| 53 | iboc60 | d_iboc | 1 | 16 | KLINE, MOST_CONTROL | |
| 54 | sat_60 | d_radio | 1 | 0 | KLINE, MOST_CONTROL | |
| 58 | adpfrr | d_adpf | 0 | 0 | ||
| 5B | dab_60 | d_dab | 1 | 0 | KLINE | DAB |
| 5F | fla_65 | d_fla | 1 | 0 | KLINE | FLA |
| 60 | kombrr | d_kombi | 1 | 20 | KLINE | KOMBI |
| 60 | kombrr_2 | d_kombi | 1 | 20 | KLINE | KOMBI |
| 61 | fbi_e65 | d_fbi | 1 | 0 | KLINE | FBI |
| 62 | mc_gw | d_mostgw | 1 | 0 | KLINE, MOST_ASYNC | |
| 63 | mmi_gt | d_mmi | 1 | 0 | KLINE, MOST_ASYNC | MMIGT |
| 64 | pdc_e65 | d_pdc | 1 | 0 | KLINE | PDC |
| 64 | pdc_65_2 | d_pdc | 1 | 0 | KLINE | PDC |
| 65 | bzm_e65 | d_bzm | 1 | 0 | KLINE | |
| 66 | bzmf_e65 | d_bzmf | 1 | 0 | KLINE | |
| 68 | ecf_e65 | d_ecf | 1 | 0 | KLINE | |
| 67 | ec_e65 | d_ec | 1 | 0 | KLINE | |
| 69 | fah_65_2 | d_fah | 1 | 0 | KLINE | FAH |
| 6D | fas_65_2 | d_fas | 1 | 0 | KLINE | FAS |
| 6A | bfh_65_2 | d_bfh | 1 | 0 | KLINE | BFH |
| 6E | bfs_65_2 | d_bfs | 1 | 0 | KLINE | BFS |
| 6B | hkl_e65 | d_hkl | 1 | 0 | KLINE | HKL |
| 6C | kfs_rr | d_kfs | 1 | 0 | KLINE | KFS |
| 70 | lm_e65_2 | d_lm | 1 | 0 | KLINE | LMA |
| 70 | lm_ahl_2 | d_lm | 1 | 0 | KLINE | LMA |
| 73 | cid_60 | d_cid | 1 | 0 | KLINE | |
| 74 | cidf65 | d_cidf | 1 | 0 | KLINE | |
| 75 | cidf2rr | d_cidf2 | 1 | 0 | KLINE | |
| 78 | ihkarr | d_klima | 1 | 0 | KLINE | IHKA |
| 7D | fdm_65 | d_fdm | 0 | 0 | ||
| 9E | ueb2 | d_009e | 0 | UEB |
